#### HEAVY DUTY TANDEM AXLE EQUIPMENT TRAILER

The 14ET Super Duty Tandem Axle Equipment Trailer from Big Tex has an 83-inch width, multiple length options and a flush floor, providing versatility and exceptional value. 7,000-pound axles give the 14ET added weight capacity for unmatched durability and strength.

#### SPECS

AXLE (2) 7,000# EZ Lube w/Electric Brakes

JACK 12,000# Drop Leg Jack-Side Wind

TIRE ST235/80 R-16 Load Range E

FLOOR 2" Treated Pine or Douglas Fir*

FRAME 6" Channel

WHEEL 16" x 6"; Black Mod 8 Bolt

FINISH Superior Quality Finish is Applied for a Highly Decorative and Protective Finish.

LIGHTS L.E.D. D.O.T. Stop, Tail, Turn & Clearance

TONGUE 6" Channel Fold Back/Wrap, 10" I-Beam on GN

COUPLER Adjustable 2-5/16" 14,000# Cast

FENDERS 9" x 72" Double Broke Diamond Plate w/Back (Removable)

G.V.W.R. 14,000#

UPRIGHTS NONE

ELEC. PLUG 7-Way RV

HITCH TYPE Bumper Pull

SUSPENSION Multi-Leaf Slipper Spring w/Equalizer

CROSSMEMBERS 3" Channel on 16" Centers

FINISH (Prep) Steel is Cleaned to Ensure a Professional Smooth Finish.

SAFETY CHAINS 3/8" Grd. 70 w/Safety Latch Hook (2 ea)

FRONT STOP RAIL 3/16" Fabricated Front Stop Rail

G.A.W.R. (Ea. Axle) 7,000#

3' KNEE RAMPS
