#### **THIS TRACTOR COMES WITH:** TX47 66" Bucket: Lift Capacity to Max Height at Pivot Pin 2,152 lbs TX47T06381 Hybrid Tires 3-Range HST Transmission All-Season Cab ####
# DETAILED SPECS ON THE T474 ENGINE Engine manufacturer TYM A2300N2 Type Natural Aspiration Gross engine power 48.3 hp | 36 kW PTO power 35.9 hp | 26.4 kW Rated engine speed 2600 rpm No. of cylinders 4 Displacement 139.5 cu. in. Air cleaner Single Dry Alternator 12V, 70A Fuel system IDI POWERTRAIN Transmission type Mechanical No. of speeds F12xR12 Max. traveling speed 14.9 mph Brakes Wet Disc Steering Hydrostatic Clutch Dry Single Plate HYDRAULIC SYSTEM Pump type Dual Gear Pump Implement flow 7.66 gpm Steering flow 4.25 gpm Total flow 11.91 gpm Category, 3-point hitch I Hitch lift capacity 2688.8 lb Hitch lift capacity at 24 inches behind link ends 1508.4 lb Lift control type Position No. of standard remote valves 1 PTO PTO type Independent PTO control Electric/Hydro PTO rear 540 rpm CAPACITIES Fuel tank 9.0 gal Coolant 6.9 qt Crankcase 6.8 qt Transmission/Hydraulics system 8.5 gal Front axle 8.6 qt DIMENSIONS & WEIGHTS Overall length with 3-point hitch 131 in. Overall width 54.5 in. Wheelbase 69.7 in. Height to top of ROPS 94.5 in. Min. ground clearance 12.8 in. Min. turn radius with brakes 106.7 in. Min. turn radius without brakes 117.5 in. Weight with ROPS 3289 lb Weight with cab 3607 lb Height to top of cabin 92.51 in. STANDARD TIRES R1 Agricultural - Front Farm Specialist 7-16 NHS TL 6PR R1 Agricultural - Rear Farm Specialist 11.2-24 NHS TL 6PR R3 Turf - Front Multi-Trac CS 27x8.50-15 NHS TL 4PR R3 Turf - Rear Multi-Trac CS 41x14.00-20 NHS TL 4PR R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR | | | --- | |
