# T754Series 4, Compact Utility Tractor

With engineering that enhances efficiency and deluxe features that you expect of a TYM Series 4 tractor, the T754 enables all-around productivity, for your operations.
LOADER TX75SL: TX75U00712

# Engine

Engine manufacturer: Deutz TCD2.9L4
Type: Turbo
Gross engine power: 74 hp | 55.4 kW
PTO power: 64.1 hp | 47.8 kW
Rated engine speed: 2200 rpm
No. of cylinders: 4
Displacement: 177 cu. in.
Air cleaner: Dual Dry
Alternator: 12V, 95A
Fuel system: CRDI

# Powertrain

Transmission type: Power Shuttle
No. of speeds: F16xR16 (creep interlock)
Max. traveling speed: 24.1 mph
Brakes: Wet Disc
Steering: Hydrostatic
Clutch: Dry Single Plate _ M, Wet Multi Plate _ PS
hydraulic system
Pump type: Dual Gear Pump
Implement flow: 10.3 gpm
Steering flow: 5.8 gpm
Total flow: 16.1 gpm
Category, 3-point hitch: II
Hitch lift capacity: 5154 lb
Hitch lift capacity at 24 inches behind link ends: 3481 lb
Lift control type: Position/Draft/Mech
No. of standard remote valves: 2

# PTO

PTO type: Independent
PTO control: Electric/Hydro
PTO rear 540/750, 540/1000 (Opt) rpm

# Capacities

Fuel tank: 23.8 gal
Coolant: 10.6 qt
Crankcase: 8.5 qt
Transmission/Hydraulics system: 18 qt
Front axle: 4.3 gal
dimensions & weights
Overall length with 3-point hitch: 157.5 in.
Overall width: 76.4 in.
Wheelbase: 86.1 in.
Height to top of ROPS: 103.3 in.
Min. ground clearance: 18.3 in.
Min. turn radius with brakes: 145.7 in.
Min. turn radius without brakes: 162.8 in.
Weight with cab: 6316 lb

# Tires

# R4 Industrial - Front: Trac Chief 15-19.5 NHS TL 6PR. R4 Industrial

Rear: Xtra Grip 18.4-24 NHS TL 8PR
