### **WILDERNESS ADDITION UPGRADES INCLUDED**

**Included:** HD Bumper with LED Light, Custom Color: Forest Green, Real Tree Camo Hood, Split Windshield, CV Guards, Metal Roof, EPS Power Steering, Armory Rack, Dome Light, 20" Red LED Hunt Light, Rear Work Light, USB Charger, Center Console with Lockable Storage, Rearview Mirror, Front Hood Rack.

Power: 48V Lithium-Ion battery powerplant
Torque: 88.5Ft-Lbs
Drivetrain: 4x4 with Rear Locking Differential
Bed Capacity: 500 Lbs.
Tow Capacity: 1,500 Lbs.
Speed: 30 Mph
Passengers: 2
Warranty: 1 Year Factory Warranty

**POWER / MOTOR**
**AC Motor powered by a 48V Lithium-Ion battery powerplant (8.0kW)**

**SPEED**
**30MPH* (24MPH with Rear Flip Seat)**

**RANGE**
**Up to 50 miles***

**STARTING**
**Keyed on/off**

**BATTERY**
**48V 160AH Lithium-Ion**

**TRANSMISSION**
**Direct drive**

**ALTERNATOR**
**Converter / 40 amps**

**TRANSAXLE**
**Model 24 Schafer**

**DIFFERENTIAL**
**Cable Activated Rear Locking**

**DRIVE**
**4wd (Switch engaged on demand, 4 wheel drive)**

**FRONT SUSPENSION**
**Double A-arms, adjustable coil over shock with up to 8" travel**

**REAR SUSPENSION**
**Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coil over shock with up to 8" of travel**

**BRAKE SYSTEM**
**4 wheel disc, hydraulic brake / hand-operated parking brake**

**TIRES**
**25" Standard HD DOT / Radial 8 Ply Tires on 12" Steel Wheels**

**DIMENSIONS**
**110" L x 58" W x 76" H (110" L with poly bed)****

**WHEEL BASE**
**73"**

**TURNING RADIUS**
**9' inside radius**

**GVWR**
**2,220 lbs.**

**CURB WEIGHT**
**1,350 lbs.**

**BED MATERIAL**
**"Poly Bed" with stake pockets**

**BED DIMENSIONS**
**35.25" L x 41.5" W x 11" D**

**GROUND CLEARANCE**
**11"**

***BED CAPACITY**
**Poly - 9 cu.ft. / 500 lbs.**

**TOWING CAPACITY**
**1,500 lbs.**

**TOTAL CAPACITY**
**900 lbs.**

**WARRANTY**
**1 year motor / all other 1 year limited, 5 year Lithium battery**

**ADDITIONAL FEATURES**
**On-board charger, DOT certified 3pt lap / shoulder belts for driver & passenger, 12V/18W LED headlights, 2" rear and front receiver hitch, welded steel frame, Single 12V auxiliary outlet for accessories, polyurethane powder paint. Complete weather-sealed wiring connections. Wide slection of additional accessories available along with three bed options. In-dash, hour meter standard. LED true state of charge meter for the 48 volt system is standard. Low charge audible warning. Battery shut down switch. Electric accelerator pedal.**

**HILL CLIMBING CAPABILITIES**
**Your AMP is capable of climbing continuous inclines up to 25 degrees. Depending on the passenger(s) and cargo weight, expect top speed between 5-10 MPH.**
