7'x14' Midsota NHV14S-BP-154 Dump
Brand
Midsota
GVWR (lbs)
15400 lbs
GAWR (lbs/axle)
7000 lbs/axle
Curb Weight
4600 lbs
Payload
10800 lbs
Width
82"
Length
20'
Overall Length
228.5
Deck Height
25
Coupler Height
11.5-19.5
Gate
Combo Barn Door Spreader Gate with Cambar, Spring-Loaded Door Hold-Backs
Length Deck
168
Height Coupler
11.5-19.5
Height Interior
24
Height Deck
25
Type
OPEN
110V Electrical
On-Board Charger 4 Amp (110V Plug In)
12V Electrical
12 Volt DC 31 Battery
Axle
(2) 7000 lb. Drop Slipper Spring Brake
Breakaway
Battery, Switch, and Lanyard
Connector Plug
Round 7-pin Cold Weather (-85)
Coupler
2-5/16'' Adjustable EZ Latch 4-Bolt Flat Plate
Crossmembers
3" Steel Channel, 16" On-Center
Decking
7-Gauge, One-Piece Smooth Steel
Exterior Finish
Industrial Grade Polymer Finish
Exterior Lights
Full LED, DOT Compliant
Exterior Storage
A-Frame Steel Lockable Toolbox, Pallet Fork Carrier, Spare Tire Carrier
Fenders
Double Break Tread Plate
Frame
6" x 4" Steel Tube
Hubs
Easy Lube
Hydraulic Components
Power Up, Gravity Down (Scissor Lift Hoist), Push Button Control with 15' Lead
Integrated Step(s)
Side Steps
Misc.
Greaseless Pivot Pins (Neverlube), Pallet Fork Holders
Mud Flaps
Yes
Ramp(s)
4" x 72" Steel Ladder Style (Slide-In with Carrier)
Safety Chains
DOT Compliant
Sides
11-Gauge Formed Sides, 24" Tall
Stabilizers
Zinc Plated, Rear Drop Leg Jacks
Tarp
18' Mesh Tarp Kit (Installed), Anti-Sail Kit with Integrated Tie-Down, Integrated Tarp Mount and Shroud, Tarp Brackets
Tie Downs
(6) 5/8" D-Rings, Stake Pockets
Tires
ST235/80R16E 10-PR
Tongue
6" x 3" Steel Tube
Tongue Jack
12K Drop Leg, Set-Back
Top Rail
3" x 2" Steel Tube
Warranty
Limited 5-Year Warranty
Wheels
16", 8-Hole Steel
