82 x 16' 17.6K BP Carrier

Brand

Midsota

GVWR (lbs)

17600 lbs

GAWR (lbs/axle)

8000 lbs/axle

Curb Weight
3580 lbs

Payload

13750 lbs

Width

82

Length

16

Overall Length

275

Deck Height

28

Coupler Height

21-30

Height Coupler

21-30

Height Overall

73

Height Deck

28

Type

OPEN

110V Electrical

On-Board Charger 4 Amp (110V Plug In)

12V Electrical

12 Volt DC 31 Battery, 22K Warrior Winch (In Protected Box)

Axle

(2) 8000 lb. Slipper Spring Brake

Breakaway

Battery, Switch, and Lanyard

Connector Plug

Round 7-pin Cold Weather (-85)

Coupler

Adjustable Pintle Ring, 30 Ton

Exterior Finish

Industrial Grade Polymer Finish

Exterior Lights

(2) LED Swivel Loading Light (2,000 Lumens), Full LED, DOT Compliant

Exterior Storage

Large Hydraulic Pump Box with Divider, Interior Light and Gas Spring, Spare Tire Carrier

Fenders

HD Reinforced Tread Plate

Frame

8", 15 lb/ft I-Beam

Hubs

Oil Bath

Hydraulic Components

Power Up, Power Down (Scissor Lift Hoist), TUFF® Wireless Controller

Tarp

22' Mesh Tarp Kit (Installed), Anti-Sail Kit with Integrated Tie-Down, Integrated Tarp Mount and Shroud

Tires

215/75R17.5J 18-PR

Tongue

8" Flange, 15 lb/ft I-Beam

Tongue Jack

12K, 2-Speed Drop Leg
