7'x20' Timpte 720 Equipment



OVERVIEW7000 GVW Trailers

Do you need space to haul medium-sized equipment? Our 7,000 GVW trailer models have you covered. These trailers are designed specifically for hauling sports cars, eliminating the need for ramps, and offering a wide variety of additional options to protect cargo.

SPECS

MODEL TYPE 720

OVERALL WIDTH 102 IN.

OVERALL LENGTH 25 FT. 1 IN.

TONGUE LENGTH 61 IN.

DECK HEIGHT 18 IN.

GROUND CLEARANCE 11 IN.

LOADING ANGLE 4°

DECK/FRAME MATERIAL ALUMINUM (EXTRUDED)

FRAME CONSTRUCTION A-FRAME

C-CHANNEL SIZE 6 IN.

WHEEL SIZE 14 IN.

WHEEL BOLT PATTERN 5 -- 4.5

TIRE SIZE ST205/75R14

TIRE LOAD RANGE D

TIRE LOAD RATING 2,040 LBS

FENDER FIXED

AXLE ROTATING TORSION

BRAKES ELECTRIC

COUPLER 2 5/16 IN

COUPLER POSITION FIXED

JACK STYLE SIDE CRANK

JACK RATING 2,000 LBS

LIGHTING LED

D-RING TIE-DOWNS FOUR
