x American LandMaster L7X - 4X4 UTV



OVERVIEW

Introducing the industry's hardest working, smoothest riding UTV of it's class. Built to tackle your toughest jobs and doubling as your biggest thrill-ride, the L7 is the most versatile UTV out there. Whether you just want a fun vehicle to drive on trails, or a more aggressive, rugged vehicle to take on big jobs, the L7 is uniquely designed to cater to both lifestyles.

Thanks to our unique L-ROSS (Landmaster Ride Optimization Suspensions System) you'll barely notice the rumble strips, railroad ties, or large rocks you just plowed over. Your life will get a whole lot easier knowing you can tackle heavy jobs, loaded trails, tight corners, and muddy trails. Plus, you'll have added comfort even in the most uncertain environments due to our unique coil over shock setup and supersport trailing arm.

UPGRADES INCLUDED:

1. TRAIL PACKAGE

Winch, Roof, Split Windshield, CV Guards, USB Port, Center Console with Lock

2. Convertible Steel Bed / Flat Bed

3. Street Light & Horn Package

4. Front LED Light

5. Side Mirrors

6. Rear Mirror

SPECS

POWER 21hp | 694cc LandMAXX EFI Commercial Power Engine by Kohler Command Pro ECH650 rated at 21hp 4-stroke OHV V-twin with oil pressure warning light. Remote Air Cleaner

SPEED Up to 34 mph

FUEL CONSUMPTION Up to 28 mpg

RANGE Up to 100 miles

STARTING 12V keyed ignition with recoil backup

BATTERY 12V / 360 cca utility class

SPARK PLUG NGK C7HSA

FUEL CAPACITY 5.0 gal

ALTERNATOR 25 amp

TRANSMISSION CVT automatic

TRANSAXLE Gear drive Schafer/DANA oil-filled transaxle

DIFFERENTIAL Cable Actuated Rear-Locking

DRIVE Switch engaged on demand, 4 wheel drive

FRONT SUSPENSION Double A-arms, adjustable coil over shock with up to 8" travel

REAR SUSPENSION Independent trailing arm, with radius rod, adjustable camber & tow control, dual-rate coil over shock with up to 8" of travel

BRAKE SYSTEM 4 wheel disk, hydraulic brake. Trans-axle mounted rotor with mechanical caliper parking brake with indicator light.

TIRES 25 x 8 - 12 (front) 25 x 10 - 12 (rear)

DIMENSIONS 95'' L x 59'' W x 76'' H

WHEEL BASE 73''

TURNING RADIUS 12' inside radius

CURB WEIGHT 1200 lbs.

BED MATERIAL Structural foam "Poly Bed" with stake pockets

BED DIMENSIONS 35.25'' L x 41.5'' W x 11'' D

GROUND CLEARANCE 11"

BED CAPACITY L-ROSS - 500 lbs. / HD-LROSS - 700 lbs. Poly - 9 cu.ft. / Steel - 11 cu.ft.

TOWING CAPACITY 1500 lbs.

TOTAL PAYLOAD L-ROSS - 900 lbs. / HD-LROSS - 1,100 lbs.
