ENGINE

Fuel management

Carburettor

Inclined position max.

20,0 °

Engine operating mode

four-stroke

Operating Engine speed

3.520 1/min

Fuel consumption

0,2 GPH US

CO2 (NRSC)

757,00 g/KWh

Standard (Power max.)

SAE J1349

Standard (Effective power)

ISO 3046 IFN

Tank capacity

1,0 gal US

Nominal Engine speed

3.600 1/min, 3.600 1/min

Electrode distance

0,028 - 0,032 "

Oil filling max.

0,2 gal US

Effective power

4,2 hp, 4,8 hp

Battery capacity (nom. value)

0 Ah

Air cleaner

Dry air filter

Power rating max.

4,8 hp

fuel type

Gasoline

Cooling

air cooling

Exhaust-gas limit

EPA4/08, EU Stage V

Oil specification

SAE 10W-30

Starter battery Voltage

0 V

Engine speed (Power max.)

3.600 1/min

Starter type

Recoil starter

Operating power

3,9 hp

Oil filling min.

0,2 gal US

Engine type

Gasoline engine

Cylinder

1

Engine Manufacturer

Honda

Standard (Operating power)

ISO 3046 IFN

Cylinder capacity

9,9 Inch3

Spark plug(s)

NGK BP-6 ES

Oil volume incl. filter change

0,2 gal US

MECHANICAL - OUTPUT DETAILS

Vibrations

5.880 1/min

Forward running

1,4 fps

Transmission

FKK-KR

Gradeability

36,4 %

Centrifugal force

3.372 lbf

Vibrations (Hz)

98,0 Hz

Area capacity

8.073,0 ft2/h

ENVIRONMENT DATA

Operating temperature range

5 - 113 °F

Sound power LWA, guaranteed

108,0 dB(A)

Storage temperature range

5 - 104 °F

HAV summation (average value)

13,5 ft/s2

Uncertainty in measurement HAV

1,6 ft/s2

HAV summation (Standard)

EN 500-4

Sound level LpA

95,0 dB(A)

Sound power LWA (Standard)

EN 500-4

Sound power LWA, measured

107,0 dB(A)

MECHANICAL DETAILS

Lenght Drawbar in op. pos.

38,2 "

Operating weight

172,0 lb

Height

26,1 "

Underclearance

26,1 "

Width

19,7 "

Custom Attributes

Model series

BPS
