OPERATING FLUIDS

Water tank capacity

34,6 gal US

ENGINE

Power rating max.

20,2 hp, 20,2 hp

Engine operating mode

four-stroke, null

fuel type

null, null

Cooling

null, air cooling

Oil specification

null, null

Operating Engine speed

3.100 1/min, null

Fuel consumption

1,6 GPH US

Engine speed (Power max.)

null, 3.600 1/min

Starter type

null, null

Engine type

Gasoline engine, Gasoline engine

Cylinder

2, 2

Engine Manufacturer

Honda, Honda

Standard (Operating power)

null, null

Cylinder capacity

null, null

Tank capacity

6,3 gal US

Oil filling max.

null, null

MECHANICAL - OUTPUT DETAILS

Oscillation Angle

12 °

Linear force dynamic front

424,2 000014

Gradeability max. (without vib

30,0 %

Centrifugal force

3.400 lbf

Linear force static (rear)

175,3 000014

Force/Drum (dyn.) front

3.372 lbf

Linear force static (front)

139,7 000014

Area capacity

77.995,9 ft2/h

Travel speed

0,0 - 5,0 m/H

Force/Drum (dyn.) rear

0 lbf

Travel speed (reverse)

0,0 - 5,0 m/H

Linear force dynamic rear

0,0 000014

SHIPPING AND STORAGE

Imperial

Width for shipping

41,7 "

Shipping weight

2.288,4 lb

Height for shipping

69,0 "

Length for shipping

79,8 "

MECHANICAL DETAILS

Imperial

Curb clearance right

15,7 "

Drum diameter

22,0 "

Wheelbase

52,0 "

Drum width

35,4 "

Weight Drum (static) Front

1.108,9 lb

Side clearance left

1,7 "

Side clearance right

1,7 "

Thickness Drum Sheet

0,4 "

Length

74,0 "

Weight Drum (static) Rear

1.399,9 lb

Curb clearance left

15,7 "

Height

90,6 "

Turning radius inside

76,8 "

Width

38,8 "

CHASSIS

Imperial

Steering

hydraulics

Steering angle max.

34

Brake

mech. parking brake
